FunctionDisplayPart
Button to exit to Microsoft Windows desktop.EXIT PROGRAM6
Button to open the User Adminstration
screen, see Appendix B Add and remove
users, on page 298. These functions are avail-
able only to an Administrator.
USER ADMIN
1
7
Button to open the Setup screen.
2
SETUP
1
8
Button for changing between FlexFactory
control and local control.
Request FlexFactory Control
/ Release FlexFactory Con-
trol
9
Version number of the local control software.PLC/HMI SW version10
Instrument control option: FlexFactory control
or local control.
FF Control Option11
PROFIBUS node number (applicable if the
system is controlled by FlexFactory).
Profibus Node12
Instrument number in FlexFactory (for
FlexFactory connected systems).
Remote HMI Mixer #13
Instrument number in customer equipment
inventory.
Customer Equip #14
Instrument serial number.XLX Mixer #15
1
This button is visible only for administrators.
2
This screen is for GE use only.
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 91
4 User interface
4.2 Adjustment and control screens
