4-2 Setup and Calibration
Selecting the Active
Curve
At times it will be desirable to view a curve other than H2/Air. For
example, during the first stage of a shutdown, it will be necessary to
view the H2/CO2 curve. To select the XDP active curve, access the
User Program as described on page 3-4, and proceed as follows:
Press
[ESC] as many times as necessary to return to normal RUN mode,
or proceed to the appropriate section of this chapter to continue
programming the XDP.
Cal Opt Disp
Use the [W] and [X] keys to
select
[Cal] and press [ENTER].
Cal
Opt Disp Press [ENTER].
1:Cal
Range
Cal If necessary, use the [W] and
[
X] keys to select [Range] and
press
[ENTER].
Slct Cal Menu Item
Range
Cal Press [ENTER].
Select-Active-Curve
Select-Active-Curve Use the [S] and [T] keys to
select the desired gas mixture
to be monitored and press
[ENTER]. [H2/AIR is used as an
example in this manual.]
H2/AIR
H2/CO2
AIR/CO2
Range
Cal Press [ESC] three times to
return to the main menu.
Select-Active-Curve
