GE XDP-H2 User Manual

January 2008
4-12 Setup and Calibration
Testing the System Analog
Output
Enter the system analog output menu, as described on page 4-8, and
proceed as follows:
Note: The Aout Type, Zero Setpoint, and Span Trim options are also
available in the above list box.
At the next prompt, enter the desired “Test Percent” value, which is
the system analog output value (expressed as a percentage of the
system analog output span) used by the meter as a
TEST signal.
Enter the desired test percent at the above prompt to verify that the
analog output device is accurately recording the specified test values.
When done, press
[ENTER].
IMPORTANT: The edit box above must be exited (by pressing
[ENTER] while in edit mode) and re-entered for the
analog output device to drive the previously entered
value. Entering the span or zero trim spin boxes will
also output the entered test perecent.
Either press
[ESC] until you return the User Menu or proceed to the
appropriate section to continue setting up the system analog output.
User..Aout Use the [
S] and [T] keys to
select
[Test], and press [ENTER].
Span Setpoint
Test
Zero Trim
User Aout Aout-Test
Use [W] and [X] to position the
cursor. Then, use [
S] and [T]
to increment the test percent to
the desired value.
Test Percent
xx
s
User..Aout You are now back at the sys-
tem analog output setup menu.
Span Setpoint
Test
Zero Trim
