5-14 Advanced Programming
Factory-Level
Programming
To program any of the features described in this section, access the
User Program as described on page 3-4 and enter the correct value
(Consult Factory) at the password prompt. Then, refer to Figure C-4
on page C-4 and go to one of the following sections:
• entering the sensor serial number
• configuring the 4-20 mA input
• entering factory calibration data
• loading software
Entering the Sensor Serial
Number
To enter the XDP system transmitter serial number, access the setup
menu as described on page 5-4 and complete the following steps:
Note: “4-20mA-Out” and “Factory Calibration” menu options also
appear on the above list.
At the next prompt, enter serial number of the transmitter, as provided
by GE Sensing.
To continue programming the setup menu, proceed to the appropriate
section for instructions. Otherwise, press
[ESC] four times to return to
live measurement mode.
Range Cal Setup Use the [S] and [T] keys to
select
[Serial Number] and
press
[ENTER].
Alarms
Serial Number
4-20mA-Input
Sensor-Serial-Num Use [
W] and [X] to position the
cursor under the desired char-
acter. Then, use [
S] and [T] to
increment the value. Press
[ENTER] when done.
Sensor-Serial-Num
xxxxx
s
Range Cal Setup You are now back at the setup
menu.
Alarms
Serial Number
4-20mA-Input
