5-2 Advanced Programming
Setup-Level
Programming
To program any of the features described in this section, access the
User Program as described on page 3-4 and enter the correct value
(Consult Factory) at the password prompt. Then, refer to Figure C-3
on page C-3 and go to one of the following sections:
• configuring the display
• configuring the 4-20 mA output
• configuring the Low and Low Low alarms
• testing all XDP alarms
Configuring the Display After powering up, the XDP performs a series of internal tests. If the
display has not yet been configured, the following screen appears:
Before any data can be displayed, the XDP must be configured for the
desired display parameter. To set the active curve that is output to the
digital display, complete the following steps:
x Unassigned ±
The padlock at the upper right
means that the menus are cur-
rently password protected.
Password
Use [W] and [X] to position the
cursor under the desired char-
acter. Then, use [
S] and [T] to
increment the value. Press
[ENTER] when done.
Enter Password
xxxx
s
Cfg Cal Opt
Disp If necessary, use the [W] and
[
X] keys to select [Cfg] and
press
[ENTER]. (Notice Disp is
unavailable at this time.)
Cfg
Cal Opt Disp Press [ENTER].
1:Cfg
To Next Page
