GE XDP-H2 User Manual

Advanced Programming 5-3
January 2008
Configuring the Display
(cont.)
Note: “0:Analog Output” is also available in the above list box.
To select the desired output(s), complete the following steps:
1. Use the [
S] and [T] keys to highlight a specific system output.
For this example, make sure that
[0:Display] is selected as one of
the outputs to be displayed.
2. Use the [
W] and [X] keys to select “Add” or “Remove” and press
the
[ENTER] key to change the status of the selected output. An
output is selected if an asterisk (*) appears to its left.
3. When all of the desired outputs have been selected, use the [
W]
and [
X] keys to select “OK” and press the [ENTER] key.
From 1:Cfg The currently active range is
listed. Press
[ENTER] to select
this range. (H2/AIR is used
here as an example.)
H2/AIR
From 1:Cfg H2/AIR A list of available units is
shown. Use the [
S] and [T]
keys to select the desired units
and press
[ENTER].
mA
pcnt
From 1:Cfg H2..pcnt A list of the available output
devices is shown. Follow the
instructions below to select the
desired outputs.
*0:Display
*0:Fault Alarm
Add Remove
OK
Cancel
From 1:Cfg H2/AIR Press
[ESC] three times to
return to the main menu. Then,
press
[ESC] again to return to
run mode.
mA
pcnt
1 H2/AIR
The selected display is shown.
[Notice that the padlock no
longer appears, as the menus
are now unlocked.]
18.73 mA
