Setup and Calibration 4-11
January 2008
Setting the Span Setpoint Enter the system analog output menu, as described on page 4-8, and
proceed as follows:
Note: The Aout Type, Zero Trim, and Span Trim options are also
available in the above list box.
At the next prompt, enter the desired span setpoint (the percentage of
target gas that corresponds to the upper end of the specified system
analog output range minus the zero setpoint).
Either press
[ESC] until you return the User Menu or proceed to the
appropriate section to continue setting up the system analog output.
User..Aout Use the [
S] and [T] keys to
select
[Span Setpoint], and
press
[ENTER].
Zero Setpoint
Span Setpoint
Test
User Aout Span-Set Use [
W] and [X] to position the
cursor under the desired char-
acter. Then, use [
S] and [T] to
increment the value. Press
[ENTER] when done.
Span Set
xxxx.xxxxx
s
User..Aout You are now back at the sys-
tem analog output setup menu.
Zero Setpoint
Span Setpoint
Test
