Advanced Programming 5-17
January 2008
Entering Factory
Calibration Data (cont.)
Caution!
Incorrect entry of the calibration data points will cause
the instrument to give unreliable results.
At the following prompt, enter the (mA, pcnt) values for each of the
known data points for the selected gas curve. To enter the data,
complete the following steps:
1. Use [
W] and [X] to position the cursor at the desired position in the
mA value, and use [
S] and [T] to increment the number.
2. Use [
W] and [X] to position the cursor at the desired position in the
pcnt value, and use [
S] and [T] to increment the number.
3. Use [
W] and [X] to position the cursor at the double arrows at the
far right, and use [
S] and [T] to increment the number and switch
to a different calibration point.
4. Repeat steps 1-3 until all of the data points have been entered.
To continue programming the setup menu, proceed to the appropriate
section for instructions. Otherwise, press
[ESC] four times to return to
live measurement mode.
Gas Curve: H2..Data Press
[ENTER] when all of the
data points have been entered.
mA pcnt s
xx.xxxxx
xxx.xxxx t
1..6
Gas-Curve: Press
[ESC] to return to the
setup submenu.
H2/AIR
H2/CO2
AIR/CO2
