September 2007
6-20 General Programming
PRESSURE/BACKGROUND
GRID Option (cont.)
The Point #n prompt repeats until the %O2 values for the total
number of points specified at the # Points prompt have been entered.
After all of the %O2 values have been entered, the Enter Point?
prompt appears.
The next prompt to appear depends on the above response and on
whether you selected Numeric Entry or Introduce Gases at the
Calibrate Mode prompt on page 6-5. Proceed to one of the sections
on the following two pages to continue the programming sequence:
Note: After all data points specified at the # Points prompt for the
current curve have been entered, this sequence is repeated for
the next curve. After all of the curves specified in the # Curves
prompt have been entered, the programming of the current
Pressure Grid is completed and you will be returned to the #
Curves prompt to program the next grid.
• Numeric Entry/[Y] - enter tabulated mV value
• Numeric Entry/[N] - XMO2 interpolates mV value
• Introduce Gases/[Y] - use appropriate calibration gas
• Introduce Gases/[N] - XMO2 interpolates mV value
Point #n
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
%O2 [x.xx]:
x.xx %O2, Curve #n, xxx.x mmHg
Press [Y] or [Enter] to begin
programming actual mV values,
or press
[N] to have the XMO2
interpolate the mV values.
Enter Point?
To Next Page
