Hose connection diagram with T.VIS control top
Figure 5-1 - Hose Connection Diagram
Position Designation
A Actuator
P Central air supply
X Sound absorber
Y Locking screw
Z Plug
38 / 104 - 5.5 Checking the pneumatic connection
0000000881 - 001 - EN-GB
