1. Pull the valve insert out of the hous-
ing.
®
The bearing
disk (4) and the sealing
washer (3) must not hit the stem of
the valve disk when the valve insert is
withdrawn.
3
4
Þ
The valve is now separated from the housing.
9.5 Removing the valve - 61 / 104
