168
9. TECHNICAL DATA
INPUTS 650 1250 1350
MAIN
INPUT
Sensor type TC, RTD (PT100, JPT100), IR ES1B, DC linear sensor
Accuracy TC inputs:
Calibration accuracy: < +/- (0,25% of reading value in °C +0,1°C)
Linearization accuracy: 0,1% of reading value
Cold junction accuracy: < +/- 1,5°C a 25°C room temperature)
Cold junction compensation: > 30:1 rejection to the change of the room
temperature
RTD input:
Calibration accuracy: < +/- (0,15% of reading value in °C +1°C)
Temperature drift: < +/- (0,005% of reading value in °C +0,015°C )/°C from 25°C
room temperature
Linearization accuracy: 0,1% of reading value
Linear inputs:
Calibration accuracy:< 0,1% full scale
Temperature drift: < +/- 0,005% full scale /°C at 25°C room temperature
Sampling time 60 ms / 120 ms, selectable
Digital filter 0,0...20,0 s
Temperature unit
of measurement
Degrees C / F, selectable from keypad
Signal interval Type: linear
Scale: -1999...9999, settable decimal point
TC (thermocouple)
input
Thermocouple: J, K, R, S, T, C, D
Linearization: ITS90 or custom
RTD (resistance
thermometer)
input
Resistance thermometer: PT100, JPT100
Input impedance (Ri): ≥ 30 kΩ
Linearization: DIN 43760 or custom
Max. line resistance: 20 Ω
DC linear input 0...60 mV input impedance (Ri): > 70 kΩ
0...1 V input impedance (Ri): > 15 kΩ
0...5 V / 0...10 V input impedance (Ri): > 30 kΩ
0/4...20 mA input impedance (Ri): 50 Ω
Linearization: linear or custom
AUXILIARY
INPUT
Remote setpoint 0...1 V, 0...10 V, 0/4...20 mA
Scale 0...1 V input impedance (Ri): > 15 kΩ
0...10 V input impedance (Ri): > 30 kΩ
0/4...20 mA input impedance (Ri): 50 Ω
Accuracy 0,1% f.s. ±1 digit @25 °C
CT
(ammeter)
INPUT
Type Isolated via external transformer
Number: 2 max
Max. capacity: x / 50 mA AC
Line frequency: 50/60 Hz
Input impedance (Ri): 10 Ω
Accuracy ±2% f.s. ±1 digit @25 °C
DIGITAL
INPUTS
Type voltage-free contact, or
NPN 24 V - 4,5 mA, or
PNP 12/24 V - max 3,6 mA
(for detail see electrical connections)
Isolation 500 V
Number 3 max 5 max
