OUTPUTS 650 1250 1350
Relay
(R)
Number: 4 max
Type of relay contact: NO
Max. current: 5 A, 250 VAC
Number: 4 max
Type of relay contact: NO
Max. current: 5 A, 250 VAC / 30 VDC, cosϕ = 1
Minimum load: 5 V, 10 mA
Life cycle: > 100.000 operations
Double isolation
Logic
(D)
Number: 2 max
Type: for solid-state relays
Voltage: 24 V ±10% (min 10 V @20 mA)
Isolated from main input
Triac ( long life relè)
(T)
Number: 1 max
Load: resistive
Voltage: 75...264 VAC
Current max: 1 A
Isolation 3 kV
snubber circuit integrated
zero crossing switching
Continuous
(C)
Number: 1 max
Current: 4...20 mA
R
out
: < 500 Ω
Resolution: 12 bit
Isolated from main input
Analog
retransmission
(A1)
Number: 1 max
0...10 V, max 20 mA, R
out
: > 500 Ω
0...20 mA, 4...20 mA, R
out
: < 500 Ω
Resolution: 12 bit
Isolated from main input
ALARMS
Number of alarm
functions
4 max, assignable to an output
Possible
configurations
Maximum, minimum, symmetric, absolute/relative, exclusion at firing, memory,
reset from keypad and/or contact, LBA, HB, HBB Hold Back Band if enabled
with Programmer function
