80208G_MHW_650-1250-1350_01-2017_ENG

173

Insulation Block Diagram 1250-1350

Sensor Input, Auxiliary Input, CT Input

Conﬁguration port

POWER supply

Modbus comunication port

Digital Input, Logic Output (SSR drive)

DC Output 1, DC Output W

Out 1 Relay

Out 2 Relay

Out 3 Relay

Out 3 Relay (o Triac)

Functional insulation

Reinforced insulation
