9. TECHNICAL DATA
Insulation Block Diagram 650
Sensor Input, Auxiliary Input, CT Input
Configuration port
POWER supply
Modbus comunication port
Digital Input, Logic Output (SSR drive)
DC Output 1, DC Output W
Out 1 Relay
Out 2,3,4 Relay
Out 2 Relay
Out 3 Relay (o Triac)
Functional insulation
Reinforced insulation
