171
GENERAL DATA 650 1250 1350
POWER SUPPLY
Operating voltage 100...240 VAC/VDC ±10%, 50/60 Hz
(on request 20...27 VAC/VDC ±10%)
Power dissipation 5 W max 10 W max 10 W max
Protections Overvoltage 300 V / 35 V
Connection Screw terminals and crimp connector, max. wire section 1 mm
2
CONNECTIONS
Serial configura-
tion port (for USB
connection)
Connector: microUSB
Inputs and outputs Screw terminals and crimp connector, max. wire section 2,5 mm
2
AMBIENT
CONDITIONS
Use Indoor
Altitude 2000 m max
Operating
temperature
-10 ... +55 °C (as per IEC 68-2-14)
Storage
temperature
-20 ... +70 °C (as per IEC 68-2-14)
Relative humidity 20...85% RH non-condensing (as per IEC 68-2-3)
PROTECTION
LEVEL
IP 65 on front panel (as per IEC 68-2-3)
ASSEMBLY
Positioning On panel, removable faceplate
Installation
regulations
Installation category: II; Pollution degree: 2
Isolation: double
DIMENSIONS
48 × 48 mm (1/16 DIN),
Depth: 80 mm
48 × 96 mm (1/8 DIN)
Depth: 80 mm
96 × 96 mm (1/4 DIN)
Depth: 80 mm
WEIGHT 0,16 kg 0,24 kg 0,24 kg
CE STANDARDS
EMC
(electromagnetic
compatibility)
Conforms to directive 2014/30/EU with reference to standard EN 61326-1
emission in industrial environment class A for models 650 LV
emission in residential environment class B for models 650 HV
Safety LVD conforms to directive 2014/35/EU with reference to standard EN61010-1
9. TECHNICAL DATA
