49
4.4.11. CTx - Current transformer input available
Acronym Scrolling message Submenu Attributes
CTx CURRENT TRASFORMER AVAILABLE INFO R
If present, the parameter indicates that one or more current transformer inputs are installed on the controller.
Unit of measurement: -
Options: CT1 = The device has 1 current transformer input
CT1+2 = The device has 2 current transformer inputs
4.4.12. x.IN.DG - Digital input available
Acronym Scrolling message Submenu Attributes
x.IN.DG DIGITAL INPUT AVAILABLE INFO R
If present, the parameter indicates how many digital inputs are installed on the controller.
Unit of measurement: -
Options: 1.IN.DG = 1 digital input installed on the controller
2.IN.DG = 2 digital input installed on the controller
3.IN.DG = 3 digital input installed on the controller
5.IN.DG = 4 digital input installed on the controller
4.4.13. RS485 - RS485 serial port available
Acronym Scrolling message Submenu Attributes
RS485 FIELDBUS AVAILABLE INFO R
If present, the parameter indicates that an RS485 is installed on the controller.
Unit of measurement: -
Options: -
4.4.14. Out1 - Type of output 1
Acronym Scrolling message Submenu Attributes
Out1 OUTPUT TYPE INFO R
The parameter specifies the type of output 1.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24 V logic output
CONTS = Continuous current output
4.4.15. Out2 - Type of output 2
Acronym Scrolling message Submenu Attributes
Out2 OUTPUT TYPE INFO R
present, the parameter indicates that output 2 is available on the controller and specifies the type.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24 V logic output
4. CONFIGURATION
