182 ADV200 • Functions description and parameters list
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.57 4656 Mot PhLoss holdoff ms UINT16 800 400 10000 ERW FVS
Represents the time the alarm condition has to persist before the alarm is actually generated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.58 4658 Mot PhLoss threshold A FLOAT 0.40 0 CALCF ERW FVS
Represents the output current threshold for generating the alarm.
The value has to be lower than the torque current value set in the drive.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.59 4674 Mot PhLoss speed thr rpm INT16 30 10 32000 ERW FVS
In case of failure of the connection between a phase of the motor and the drive, the alarm signal is active when
it is exceeded the speed threshold set in this parameter.
It can be used to mask the alarm at very low speed during the start and stop transients when external noise
could cause false alarm tripping.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.60 4678 Mot PhLoss code UINT32 0 0 0 ER FVS
The hexadecimal value contains information about the type of problem detected and the motor phase where
there is the anomaly.
0x0001 Error detected on phase U with motor running
0x0002 Error detected on phase V with motor running
0x0004 Error detected on phase W with motor running
0x0008 Error detected on phase U with motor running and speed ref loss
0x0010 Error detected on phase V with motor running and speed ref loss
0x0020 Error detected on phase W with motor running and speed ref loss
0x0040 Error detected on phase U during magnetizing stage ( Asynchronous motor only )
0x0080 Error detected on phase V during magnetizing stage ( Asynchronous motor only )
0x0100 Error detected on phase W during magnetizing stage ( Asynchronous motor only )
0x0200 Error detected on phase U with motor disabled (Asynchronous motor only)
0x0400 Error detected on phase V with motor disabled (Asynchronous motor only)
0x0800 Error detected on phase W with motor disabled (Asynchronous motor only)
In some cases it is possible that more bit are showed at the same time. Depending on the type of fault, in fact,
if the interruption of one phase makes that even in the other two there is no more current circulation, the dis-
played code indicates the absence of all three phases, while being just one connection failed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.61 4590 Condensat activity ENUM Disable 0 4 ERW FVS
Setting of the behaviour of the drive in the event of the [32] Condensation alarm. This alarm Indicates the
intervention of the dangerous situation of condensation inside the ADV200-LC drive series.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.62 4592 Condensat holdoff s UINT16 30 0 500 ERW FVS
Setting of the delay between the signalling of the [32] Condensation alarm and enabling of the alarm. If an
alarm condition occurs, the drive will wait for the set time before disabling the drive regulation. If the alarm is
