gefran ADV200 User Manual

202 ADV200 • Troubleshooting
Code Error message shown on
the display
Sub-code Description
41 Watchdog
Condition: may occur during functioning when the watchdog protection of the micro is activated; the alarm
is inserted in the alarm list and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code indicates the reason for the error: take note for examination with the
service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, instal-
lation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
42 Trap error
Condition: this condition can occur during operation when the trap micro protection is enabled; the alarm is
included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code (SubHandler-Class) indicates the reason for the error: take note for
examination with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting,
installation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
43 System error
Condition: this condition can occur during operation when the operating system protection is enabled; the
alarm is included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code (Error-Pid) indicates the reason for the error: take note for examination
with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting,
installation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
44 User error
Condition: this condition can occur during operation when the software protection is enabled; the alarm is
included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (Error-Pid) code indicates the reason for the error: make a note of this to
discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, instal-
lation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
45 Param error
Condition: if an error occurs during the enabling of the parameter database saved in the Flash memory; the
alarm is included in the list of alarms and alarm log.
XXXH-X The code XXXXH-X indicates the IPA of the parameter that has been set outside the range
allowed when the database is enabled.
Solution: Set the parameter causing the error to a value within the range and run Save parameter. Switch
the drive off and then switch it back on again.
If the IPA of the parameter is not shown in the manual, contact the service centre.
46 Load default
Condition: this can occur during loading of the parameter database saved in the Flash memory
it is normal if it appears in the following conditions: the first time the drive is switched on, when a new
version of the firmware is downloaded, when the regulation is installed on a new size, when a new region is
entered. If this message appears when the drive is already in use it means there has been a problem in the
parameter database saved in the Flash memory.
If this message is displayed the drive restores the default database, i.e. the one downloaded.
0001H-1 The database saved is not valid
0002H-2 The database saved is not compatible
0003H-3 The saved database refers to a different size and not to the current size
0004H-4 The saved database refers to a different region and not to the current region
Solution: Set the parameters to the desired value and run Save parameter
47 Plc cfg error
Condition: this can occur during loading of the MDPLC application
The Mdplc application present on the drive is not run.
0004H-4
The application that has been downloaded has a different Crc on the DataBlock and Func-
tion table.
