52 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.8 1014 Local/remote src LINK 16 1012 0 16384 ERW FVS
Selection of the origin (source) of the signal that switches between Remote and Local. Switching can only be
performed if the hardware is not enabled on the Enable terminal.
The signal to be associated with this function can be selected from the “L_DIGSEL3” selection list.
0 Local
1 Remote
In Remote mode the “Commands remote sel” parameter is used to congure the source of the Enable and
Start commands, which can be Terminal (standard digital input, expansion digital input) or Digital (Modbus,
Fieldbus, Prole DS402, Prole prodrive).
In Local mode the “Commands local sel” parameter is used to congure the source of the Enable and Start
commands, which can be Terminal (standard digital input, expansion digital input) or Keypad (Start key, Stop
key).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.9 1016 Terminal Start src LINK 16 1048 0 16384 ERW FVS
Selection of the origin (source) of the Terminal Start signal. Switching can only be performed if the hardware is
not enabled on the Enable terminal.
The signal to be associated with this function can be selected from the “L_DIGSEL3” selection list.
In the default condition, the origin of the Terminal Start signal is the Start output of the ForwardReverseControl
(FRC) block.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.10 1018 Digital Enable src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal that denes the enabling of the drive when the commands are sent
via serial line or eldbus. The command to be associated with this function can be selected from the “L_DIG-
SEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.11 1020 Digital Start src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the Digital Start signal. The signal to be associated with this function can be
selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.12 1022 FastStop src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) for the fast stop signal (FastStop). The terminal to be associated with this func-
tion can be selected from the “L_DIGSEL2” selection list. During the execution of the FastStop command the
ramps used are Acceleration time 3 and Deceleration time 3.
The FastStop mode (PAR 1036) parameter can be used to dene the specic operating modes for automatic
motor restart.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.13 1024 Enable cmd mon BIT 16 0 0 1 R FVS
The status of the enable command is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.14 1026 Start cmd mon BIT 16 0 0 1 R FVS
The status of the Start command is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.15 1028 FastStop cmd mon BIT 16 0 0 1 R FVS
