ADV200 • Functions description and parameters list 69
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.36 1606 An inp 1Xoffset tune BIT 0 0 1 RWZ FVS
14.48 1656 An inp 2Xoffset tune BIT 0 0 1 RWZ FVS
Self-tuning command for the offset of the relative analog input of the expansion card. Automatic ne tuning
of the input. To perform self-tuning, set the input signal to its minimum value and execute the command. The
conditions containing an offset can be compensated. When this command is sent, An inp xX offset tune is
automatically selected so that the available input signal corresponds to the zero value of the variable.
Automatic tuning can only be performed if the following condition is present:
- Input voltage less than 1V or input current less than 2 mA
Note ! The value that is obtained automatically can be changed manually, if necessary, using An inp offset xX.
If the voltage setting on the analog input is higher than 1V, the Value too low alarm is generated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.37 1608 An inp 1X gain tune BIT 0 0 1 RWZ FVS
14.49 1658 An inp 2X gain tune BIT 0 0 1 RWZ FVS
Self-tuning command for the relative analog input gain. Automatic ne tuning of the input. When this command
is sent, Analog inp 1 gain x is automatically selected so that the available input signal corresponds to the
maximum value of the variable.
Two conditions are necessary in order to perform automatic tuning:
- Input voltage greater than 1V or input current greater than 2 mA
- Positive polarity. The value that is found is automatically accepted for the other direction of rotation.
Note ! If necessary, the value obtained automatically can be changed manually via Analog inp Xx gain.
To perform self-tuning, set the input signal to its maximum value and execute the command. A multiplier factor
is calculated to apply to the input signal value (not considering the Analog inp scale parameter) to reach the
full scale value.
If the voltage setting on the analog input is less than 1V, the Value too low alarm is generated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.38 1620 Analog inp 1X filter ms UINT16 0 0 1000 ERW FVS
14.50 1670 Analog inp 2X filter ms UINT16 0 0 1000 ERW FVS
Parameters used to lter input signals to the I/O expansion card, especially if the card is used to measure mo-
tor temperature with KTY84.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.39 1612 Analog inp 1X top cnt INT16 16384 -32768 + 32767 ERW FVS
14.51 1662 Analog inp 2X top cnt INT16 16384 -32768 + 32767 ERW FVS
Setting of the upper speed reference limit as a function of the voltage (or current) of the relative analog refer-
ence of the expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.40 1614 Analog inp 1X bottom cnt INT16 -16384 -32768 + 32767 ERW FVS
14.52 1664 Analog inp 2X bottom cnt INT16 -16384 -32768 + 32767 ERW FVS
Setting of the lower speed reference limit as a function of the voltage (or current) of the relative analog refer-
ence of the expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.41 1616 Analog inp 1X offset cnt INT16 0 -32768 + 32767 ERW FVS
14.53 1666 Analog inp 2X offset cnt INT16 0 -32768 + 32767 ERW FVS
