gefran VDL200 Series User Manual

22 VDL200 • Quick installation guide - Specifications and connection
6.2 Fastening positions
33.5 (1.32)
168 (6.61)
218.3 (8.59)
164 (6.46)
9 (0.35)
374.7 (13.69)
374 (14.72)
9 (0.35)
8.34 (0.33)
B
C
115 (5.53)
320.2 (12.60)
321.2 (12.64)
7.5 (0.29)
7.5 (0.29)
C
B
148.1
(5.83)
115 (5.53)
23.5 (0.93)115 (5.53)
7.5
376.2 (14.81)
B
C
115 (5.53)
23.5 (0.93)
Fissaggio a muro • Wall mounting • Fixation mural • Wandmontagee • Fijación en pared
Taglia 3
Size 3
Grandeur 3
Größe 3
Tamaño 3
Taglia 2
Size 2
Grandeur 2
Größe 2
Tamaño 2
Taglia 1
Size 1
Grandeur 1
Größe 1
Tamaño 1
Taglie • Sizes • Grandeurs • Größen • Tamaños :
11
5.3
5.5
7
5.5
11.5
16.2
(A)
(B)
(C)
17
5.5
11.5
9
5.5
11
5.3
(A) (B) (C)
1-2 3
Recommended screws for fastening
Size 1 (..-1...) 
Size 2 (..-2...) 
 
Note! Other dimensions see chapter 4.9 Weights and dimensions.
