 LINK parameters
The parameter may assume the number of another parameter as value.
11 DIGITAL OUTPUTS
14 MOTOR DATA
15 ENCODER CONFIG
16 SPEED REG GAINS
17 REGULATOR PARAM

11
DIGITAL OUTPUTS
01/16 PAR: 1410
Di
g
output 1X s
r
c
»Drive OK
Value: 1062
E
11
DIGITAL OUTPUTS
01/16 PAR: 1410
Di
g
output 1X s
r
c
»Drive OK
Value: 1062

11
DIGITAL OUTPUTS
01/16 PAR: 1410
Di
g
output 1X s
r
c
»Di
g
ital in
p
ut 12X mon
Value: 1232

11
DIGITAL OUTPUTS
01/16 PAR: 1410
Di
g
output 1X s
r
c
» Drive ready
Value: 1064
Press E

Press EESC to cancel.
 ENUM parameters
The parameter may assume only the values contained in a selection list.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT
 
x2
04 DRIVE CONFIG
03/19 PAR: 554
Access mode
Easy
Value: 0
E

04 DRIVE CONFIG
03/17 PAR: 554
Access mode
Expert
Value: 1
Press E

Press EESC to cancel.
 Execution of commands
A parameter can be used to carry out a number of operations on the drive. For an example, see next paragraph: in this
case the request "Press E to execute" is displayed.
To execute the command, press E. During execution of the command, the “In progress
indicate that the operation is in course. At the end of execution, if the result is positive, the “Done
for few seconds. If execution has failed, an error message is displayed.
8.2.7 How to save parameters
There are two ways of saving parameters in the non-volatile memory of the drive:
1) By pressing the SAVE key on the keypad.
2) Menu 04 DRIVE CONFIG, parameter 04.01 Save parameters, PAR : 550. This is used to save changes to param-
󰀨
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT

04 DRIVE CONFIG
01/18 PAR: 550
Save parameters
Press E to exe
c
ute
E
04 DRIVE CONFIG
01/18 PAR: 550
Save parameters
In progress
04 DRIVE CONFIG
01/18 PAR: 550
Save parameters
Done

