VDL200 • Quick installation guide - Specifications and connection 45
9.1 Asynchronous motor startup wizard (with the optional keypad)
The VDL200
vector control (closed loop).
Note! Before starting, check the factory settings:
Menu 04 DRIVE CONFIG, parameter 04.2 Regulation mode, PAR: 552, default=SSC control.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT
x1
04 DRIVE CONFIG
2/19 PAR: 552
Regulation mode
SSC control
Value: 0
The STARTUP WIZARD is a guided procedure used for quick start-up of the drive that helps to set the main
parameters.
It consists of a series of questions, relating to the various sequences for entering and calculating the parameters
necessary for correct drive and lift application operation. The order of these sequences is as follows:
Electrical connections See step 1
Setting motor parameters See step 2
Autotune with motor at stand-still or coupled to the load See step 3
Setting encoder parameters (with control mode=Flux vector CL) See step 4
Setting the maximum speed reference and maximum system speed See step 6
Setting system weights See step 7
Setting application parameters See step 8
Saving parameters See step 9
The format of the function selection page is as follows:
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT
03 STARTUP WIZARD
Set motor data?
E=Yes Down=Next
Pressing the E key, the function to be programmed is accessed.
To terminate the sequence of functions and return to the menu, press the ESC key.
The end of the start-up sequence is indicated with the page:
03 STARTUP WIZARD
End of se
q
uence!
Up=Back Down=Exit
