VDL200 • Quick installation guide - Specifications and connection 7
2 - Introduction to the product
The SIEIDrive VDL200 is the result of GEFRAN’s experience in the civil lift engineering sector, gained from its
commitment to working in close partnership with leading operators in the sector to develop technical solutions and
application programs.
The VDL200 integrates the most complete and advanced lift inverter technology,
solution for lift control systems.
This drive is designed to power loads such as asynchronous motors, for applications in the lift sector.
This compact drive is suitable for installation in cabinets for roomless applications.
Designed and produced to meet the full range of requirements in the lift sector.
• Management of asynchronous motors
• 8 programmable digital inputs (NPN/PNP) + an Enable input
• 4 single-contact programmable relay outputs
• Input for 5 Vdc TTL incremental digital encoder
• 1 analog input
• Speed regulator with monitoring of the correct lifting or dropping of the machine brake according to 5.6.7 of EN
81-20:2014 and 5.8 of EN 81-50:2014 (respectively 9.11.3 and F.8 of EN 81-1:1998 + A3:2009)
• IntegratedVDL200-...-F)
• Suitable for UPS emergency operation
• Optimized sensorless control.
2.1 Dedicated features
The VDL200 incorporates basic and advanced lift functions in a single product, to ensure maximum comfort for all
systems at all times.
• Speed control
EFC
• Lift sequence
Typical sequence of input/output signals used in civil lift engineering applications such as I/O management, braking,
output contactor and door control.
• Parameters in linear unit
(fpm) or m/s for speed, m/s², m/s³ (ft/s
2
, ft/s
3
) for cabin acceleration.
• Lift mechanical parameters
Mechanical system parameters such as pulley diameter and speed ratio for converting system units and weights,
system for calculating inertia and speed regulation for the desired response.
• Ramp generation
settings. Dedicated deceleration ramp corresponding to the stop command.
• Multiple speeds
8 internally settable speed reference values. Possibility of overwriting at start-up with additional values to ensure
smooth starting.
• Pre-torque (load compensation)
• Increased overload
Overload capacity in line with typical lift application load cycles.
• Fan control logic
The fan control logic activates the internal fans according to the temperature.
•
power supply or batteries with EMS module).
• User-friendly menus
