VDL200 • Quick installation guide - Specifications and connection 53
Code Error message shown
on the display
Sub-code Description
Solution:
- Reduce the motor load.
- Increase the size of the motor.
15 Bres overload [BOL]
Condition: Braking resistor overload alarm.
The current absorbed by the resistor is greater than the rated current.
Solution:
- Check the size of the braking resistor.
- Check the condition of the braking resistor.
16 Phase loss [PHL]
Condition: Power phase loss alarm.
Solution: Check the mains voltage and whether any protections upstream of the drive have been tripped.
17 - 18 Not used
19 - 20
21 External fault [EF]
Condition: External alarm present.
A digital input has been programmed as an external alarm, but the +24V voltage is not available on the terminal.
Solution: Check that the terminal screws are tight
22 Speed fbk loss [SFL]
Condition: Speed feedback loss alarm.
The encoder is not connected, not connected properly or not powered: verify encoder operation by selecting the PAR 260 Motor speed parameter in the
MONITOR menu.
Solution:
See parameter 2172 SpdFbkLoss code for information about the cause of the alarm and chapter 10.2 Speed fbk loss [22] alarm
23 Overspeed [OS] Condition: Motor overspeed alarm. The motor speed exceeds the limits set in the PAR 4540 parameter.
Solution:
- Limit the speed reference.
- Check that the motor is not driven in overspeed during rotation.
24 Speed ref loss [SRL]
Condition: Speed reference loss alarm; occurs if the difference between the speed regulator reference and the actual motor speed is more than
100 rpm. This condition occurs because the drive is in the current limit condition. It is only available in the Flux Vect OL and Flux Vect CL mode (see PAR
4550).
Solution: Check that the load is not excessive.
25 Not Used
26 Power down [PRR] Condition: The drive was enabled with no supply voltage at the power section.
Solution: Emergency stop alarm. The Stop key on the keypad was pressed with the Stop key mode parameter set to EmgStop&Alarm in case of
Remote->Terminal Strip or Remote->Digital or Local->Terminal Strip mode.
27 Phaseloss out [PHLO] Condition:
Solution:
28 - 29
Not Used
30 Mot phase loss Condition: Output phase loss.
[MOTL] Solution: Check Drive/motor connection.
31
Ropes change
[ROPC]
This may occur in two conditions:
• the drive continues to run but the rope usage threshold set in parameter 3404 Ropes change thr has been reached;
• the drive finishes the current travel and then locks because parameter 3414 Direction counter has reached 0 (corresponding to parameter 3412
Ropes usage = 100%).
Solution: replace the ropes.
By switching the drive off and back on you can run a single travel to bring the car to a better position for the procedure.
After you have changed the ropes, reset the direction change counter to eliminate the lock condition.
32 Phasing error Condition: Error performing the motor autophasing after start command.
[PERR] Solution: Check the parameters for encoder configuration, parameter 2028 Take status and encoder electrical connection.
33 ... 40
Plc1 fault [PLC1]
...
Plc8 fault [PLC8]
Condition: Enabled application developed in the IEC 61131-3 environment has found the conditions for generating this specific alarm to be true. The mean-
ing of the alarm depends on the type of application. For more information, refer to the documentation concerning the specific application..
XXXXH-X The XXXXH-X code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: Refer to the documentation concerning the enabled application.
With regards to the standard application EFC refer to Functional Parameter Manual section LIFT ALARMS. For the applications DCP3/DCP4, EPC and CiA
417 refert to the application manual section ALARMS.
41 Watchdog [WDT]
Condition: this condition can occur during operation when the watchdog micro protection is enabled; the alarm is included in the list of alarms and alarm
log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm is the consequence of a change in the drive configuration (parameter setting, option installation, PLC application download)
remove it.
Turn the drive off and then on again.
42 Trap error [TRAP]
Condition: this condition can occur during operation when the trap micro protection is enabled; the alarm is included in the list of alarms and alarm log.
After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (SubHandler-Class) code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, installation of an option, downloading of a PLC
application), remove it.
Switch the drive off and then switch it on again.
43 System error [SYS]
Condition: this condition can occur during operation when the operating system protection is enabled; the alarm is included in the list of alarms and alarm
log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (Error-Pid) code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, installation of an option, downloading of a PLC
application), remove it.
Switch the drive off and then switch it on again.
