Printed in U.S.A. 101 913364/BP0314
01 50303765 WELDMENT, HYDRAULIC TANK 1
02 654006 FW 3/8 AWZY 1
03 139438 CS FL LOCK 3/8” x 5/8” 3
04 138877 FILTER, VENTILATION 1
05 131913 BUMPER 1
06 653034 HLN 5/16” C2ZY 1
08 131577 PLUG MORB10 1
09 055898 O-RING (included with item 8) 1
12 055064 45 MJ12-MAORB12 1
13 50301262 HOSE, MP12 x 75 IN. 1
14 230-32412 ADAP., MAORB20-BARB 1
15 077970 O-RING (included with item 14) 1
16 193743 CLAMP, T-BOLT 1.75 IN. 1
17 50301897 HOSE, LP 20 x 88.0 IN. (suction) 1
50300818 GUARD, POLY HOSE (not shown) 1
18 HOSE, HYDRAULIC RETURN 1
50301489 HOSE, MP12 x 55.0 IN. (Std. Hyd.)
50303157 HOSE, MP16 x 54.0 IN. (Aux. Hyd.)
19 274605 45 MJ16-MAORB12 1
20 273867 HOSE, MP 6 x 74.0 IN. 1
21 50301382 HOSE, MP4 x 67.0 IN. 1
22 079026 45 MJ06-MAORB06 2
23 273907 HOSE, MP8 x 49.0 IN. 1
24 076880 45 MJ08-MAORB08 1
25 134756 SIGHT PORT (oil level) 1
26 274125 O-RING (included with item 25) 1
27 122778 PLUG, MORB06 (stnd. hydraulics) 1
28 068938 ADAP., MJ06-MAORB06 * 1
29 274114 HOSE, MP 6 x 110.0 IN. * 1
* Used when machine is equipped with high-flow
hydraulics option.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
RT250 - HYDRAULIC SYSTEM
HYDRAULIC TANK
(Late-Style Tank - identified by the integrated vent fill cap item #4)
HOSE CONNECTION:
#13 connects to T1 on Pilot Pressure Manifold
#17 connects to hydraulic pump
#18 connects to hydraulic cooler (upper port)
#20 connects to auxiliary hydraulics (loader arm left side)
#21 connects to hydraulic main valve (bottom TEE)
#23 connects to "TEE" on right side drive motor
#29 connects to High-Flow hydraulics (loader arm right side)
To Next Page
