Printed in U.S.A. 79 913364/BP0314
RT250 - TRACKS
DUAL-FLANGE BOGIE WHEEL ASSEMBLY
01 271020 WHEEL, DUAL-FLANGE BOGIE ASY. 1
(includes all items shown)
02 50280157 SNAP RING 2
03 50280158 BRACKET 1
04 50280155 SEAL GROUP 2
05 50280154 ROLLER SHELL W/BUSHING 1
06 50280156 SHAFT 1
07 50280159 BRACKET W/HOLE 1
08 50280160 PLUG 1
NOTE: Quantities shown are for one dual-
flange bogie wheel assembly. When ordering
parts, be aware that the machine uses eight
dual-flange bogie wheel assemblies— four on
each side.
Item
No. Part No. Description Qty.
1
3
2
4
5
6
4
7
8
2
