Gehl RT250 User Manual

Printed in U.S.A. 61 913364/BP0314
RT250 - ENGINE
EXTERNAL COMPONENTS - FLYWHEEL HOUSING
01 50301041 COUPLER (130217) 1
02 50280003 SHCS HS M10-1.50x16 C12.9 P SP 8
03 272248 FLYWHEEL HOUSING 1
04 50280002 SHCS M10-1.5x30 C12.9 P SP 10
05 50280001 CS M10-1.5x60 C8.8 ZY SP DIN931 2
06 50301998 PLATE, CLAMP MOUNT 1
07 50300078 CS FLH M10-1.5 x 30 10.9 2
08 210-19533 HN FL CLOC 3/8 CZY 2
09 055021 CLAMP, VINYL 0.75 x 0.41 IN. 1
10 076589 CS FL LOCK 3/8" x 1" C5ZY 2
11 271341 CLAMP, VINYL 1.0 x 0.41 IN. DBL. 1
12 L45666 CLAMP, VINYL 1.0 x 0.41 IN. 1
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
1
2
3
4
5
Secures fuel line hoses (shown on the next page) and
hydraulic hoses (shown on page 111).
Mounting Bracket
(to secure hoses)
7
12
6
11
10
8
9
10
NOTE: Refer to the engine parts manual—
Form #50960058—for additional engine parts.

Gehl RT250 Specifications

General

Rated Operating Capacity	2, 500 lbs
Engine Power	74 hp
Tipping Load	5, 000 lbs
Auxiliary Hydraulics - High Flow	35 gpm
Engine Net Power	74 hp
Engine Gross Power	74 hp
Overall Length with Bucket	146.2 inches
Width	72 inches
Horsepower	74 hp
Length with Bucket	146.2 inches
