Gehl RT250 User Manual

Printed in U.S.A. 141 913364/BP0314
RT250 - DECALS
LEFT SIDE — (LATE STYLE)
01 50303567 DECAL, RT250 LH 1
02 50303562 DECAL, LIFT ARM 1
03 DECAL, JOYSTICK CONTROL (left) 1
275631 ISO (standard)
275633 ISO-DH (option)
04 184116 DECAL, 2-SPEED (set) *1
05 138711 DECAL, HYDRAGLIDE® ** 1
06 137661 DECAL, TIE-DOWN POINT (clear) 1
07 137634 DECAL, DIESEL FUEL ONLY 1
08 50302120 DECAL, IDEALTRAX 1
09 139074 DECAL, AIR CONDITIONED 1
** Set contains two decals—(1) left side and (1) right side.
** Used on machines equipped with optional Hydraglide™.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
1
2
3
(Inside Cab)
8
6
7
4
5
9

Gehl RT250 Specifications

General

Rated Operating Capacity	2, 500 lbs
Engine Power	74 hp
Tipping Load	5, 000 lbs
Auxiliary Hydraulics - High Flow	35 gpm
Engine Net Power	74 hp
Engine Gross Power	74 hp
Overall Length with Bucket	146.2 inches
Width	72 inches
Horsepower	74 hp
Length with Bucket	146.2 inches
