Printed in U.S.A. 105 913364/BP0314
RT250 - HYDRAULIC SYSTEM
HYDRAULIC FILTER ASSEMBLY
01 272452 HYDRAULIC FILTER ASSEMBLY 1
(includes items 2 and 3)
02 074830 HYDRAULIC FILTER 1
03 137360 SWITCH, FILTER RESTRICTION 1
04 139438 CS FL LOCK 3/8” x 5/8” C5ZY 4
05 055005 90 MJ12-MAORB12 1
06 50301996 HOSE, MP12 x 56.0 IN. 1
07 135025 HOSE, MP12 X 36.0 IN. 1
08 140883 90-LL MJ12-MAORB12 1
HOSE CONNECTION:
#06 connects to hydraulic main valve (T)
#07 connects to hydraulic cooler (tee - lower port)
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
