Gehl RT250 - Page 115

Printed in U.S.A. 113 913364/BP0314
RT250 - HYDRAULIC SYSTEM
PILOT PRESSURE MANIFOLD CIRCUIT
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
01 274477 PILOT PRESSURE MANIFOLD 1
02 50304010 ST MJ04-MORB06/SP 1
03 50302211 HOSE, MP 4 x 29.0 IN 1
04 055005 90 MJ12-MAORB12 1
05 50301262 HOSE, MP 12 x 75.0 IN. 1
06 054626 ST MJ08-MORB08 2
07 273926 HOSE, MP 8 x 22.25 IN. 1
08 50302080 HOSE, MP 4 x 53.5 IN. 1
09 50301292 HOSE,MP 6 x 58.0 IN. 1
10 054820 TEE RUN MJ06-MAORB06-MJ06 1
11 274023 HOSE, MP 8 x 23.5 IN. 1
12 055064 45 MJ12-MAORB12 1
13 50301295 HOSE, MP 6 x 52.0 IN. 1
14 273883 HOSE, MP 12 x 30.0 IN. 1
15 274386 HOSE, MP 4 x 53.0 IN. 1
16 274386 HOSE, MP 4 x 53.0 IN. 1
17 171629 TEE RUN MJ04-MAORB04-MJ04 2
18 274389 HOSE, MP 4 x 31.0 IN. 1
19 274389 HOSE, MP 4 x 31.0 IN. 1
20 071703 LN 3/8” CBZY 2
21 652059 CB 3/8” x 3-1/4” C5ZY 2
22 132049 TEMPERATURE SWITCH 1
23 50301629 HOSE, MP 6 x 56.0 IN. 1
24 091039 90 MJ06-FJS06 1
25 072806 T MJ06-FJS06-MJ06 1
26 054994 ST MJ06-MORB06 1
