Gehl RT250 User Manual

Printed in U.S.A. 125 913364/BP0314
RT250 - HYDRAULIC COMPONENTS
HYDROSTATIC DRIVE PUMP
55 50280103 FEEDBACK SENSOR, NON-CONT. 2
56 NSS SOCKET-HEAD CAP SCREW 4
57 NSS WASHER 4
58 50280105 O-RING 4
59 50280106 PROPORTIONAL FLOW REG. 758 4
60 50280107 WASHER 6
61 50280108 SOCKET-HEAD CAP SCREW 6
70 50280109 PLUG 1
72 50280110 RETAINING RING, INVERTED 1
74 50280111 POPPET 1
75 50280112 SPRING, COMPRESSION 1
76 50280113 SHIM AR
77 50280114 PLUG SUB-ASSEMBLY 1
78 50280115 O-RING 1
79 50280088 PIN, ROLL 2
80 50280116 CHARGE PUMP DRIVE PIN 1
(not shown)
81 50280117 GERAOTOR SUB-ASSEMBLY 1
82 50280118 O-RING 2
83 50280119 CHARGE PUMP COVER 1
84 50280120 SOCKET-HEAD CAP SCREW 4
85 50280121 PLUG 2
87 NSS SET SCREW 2
88 NSS NUT, SEALING 2
89 50280123 SET SCREW 2
90 50280124 NUT, SEALING 2
101 NSS SQUARE KEY 1
102 NSS O-RING 1
103 NSS COVER PLATE (NO THRU DRIVE) 1
104 NSS WASHER 2
105 NSS SCREW, CAP, HEX HEAD 2
110 50280153 CAP, NUT (PLASTIC) 2
118 NSS WASHER, NORD LOCK 8
119 NSS PLAIN WASHER 4
120 NSS PLAIN WASHER 4
150 50302024 PUMP, EH TANDEM HYDRO 62cc 1
(includes all items shown)
Item
No. Part No. Description Qty.
01 50280070 HOUSING 1
02 123090 PLUG 7
06 50280071 PLUG 1
07 245121 PLUG 4
08 123090 PLUG 1
10 50280072 PLUG 4
13 50280073 PLUG, EXPANDER TYPE 8
14 50280074 COUPLER 1
15 50280075 RETAINING RING 2
16 50280076 BEARING, TAPER 2
17 189754 PIN, ROLL 2
18
a
50288202 VALVE PLATE, RH (3.80) 62cc 1
20
a
50288201 ROTATING KIT (3.80) 62cc 2
21 50280081 GASKET, FLANGE 1
22 50280082 SWASHPLATE ASSEMBLY 2
24 50280083 BEARING, TAPER 1
25 50280084 SHIM AR
26 50288200 SHAFT SEAL, HIGH-PRESSURE 1
27 NSS RING, RETAINING INTERNAL 1
28 50280087 DRIVE SHAFT - FRONT (15T) 1
29 50280088 PIN, ROLL 4
30 50280089 FLANGE, FRONT (4-BOLT-C) 1
31
a
50288203 VALVE PLATE, LH (3.80) 62cc 1
34 50280081 GASKET, FLANGE 1
37 50280083 BEARING, TAPER 1
39 50280092 DRIVE SHAFT - REAR (13T) 1
40 50280093 FLANGE, REAR (charge pump side) 1
41 50280094 BOLT 8
42 50280095 FOLLOWER, SERVO-PISTON 2
43 50280096 RELIEF VALVE SUB-ASSEMBLY 4
47 50280097 PISTON RING 4
48 50280098 SERVO PISTON ASSEMBLY 2
50 50280099 O-RING 2
51 50280100 SERVO CAP PLUG 2
53 50280101 NUT, SEALING 2
54 50280102 MAGNET CARRIER 2
Item
No. Part No. Description Qty.

Gehl RT250 Specifications

General

Rated Operating Capacity	2, 500 lbs
Engine Power	74 hp
Tipping Load	5, 000 lbs
Auxiliary Hydraulics - High Flow	35 gpm
Engine Net Power	74 hp
Engine Gross Power	74 hp
Overall Length with Bucket	146.2 inches
Width	72 inches
Horsepower	74 hp
Length with Bucket	146.2 inches
