Printed in U.S.A. 13 913364/BP0314
01 240645 WEATHERSTRIP, WINDOW 1
02 241544 RIPCORD, WEATHERSTRIP 1
132166 TAG, RIP CORD (not shown) 1
132294 RING, RIP CORD TAG (not shown) 1
03 243270 WINDOW, REAR (standard) 1
04 N/A 0
05 005073 CLEVIS PIN 3/8” x 1-1/4” 4
071858 COTTER/HAIRPIN 1/8x1-15/16 4
06 50303213 GAS CYLINDER, CAB TILT (stnd.) 2
50303211 GAS CYLINDER, CAB TILT (option) * 2
07 650631 CS 5/8” x 4” C5ZY 2
08 651150 FW 5/8” AWZY 4
09 274203 WASHER, PLASTIC 1” 4
10 241357 ISOLATOR 2
11 071709 LN CTR 5/8” CBZY 2
* Stronger gas cylinder - used when machine is equipped
with optional cab door.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
RT250 - CAB
CAB TILT AND REAR WINDOW
