Printed in U.S.A. 19 913364/BP0314
RT250 - CAB
HEADLINER - HEAT-A/C DUCTS — (OPTION)
01 HEADLINER 1
275087 (No heater or A/C) - (standard)
275236 (Equipped with heat-A/C) - (option)
02 651308 PHMS CR 1/4” x 3/4” ZB AR
03 275353 PLATE, COVER (without heat-A/C) * 2
04 274868 PLATE, FILTER (with heat-A/C) ** 2
05 242832 FILTER, RECIRCULATION AIR 2
06 651813 PHMS CR 1/4 x 1-1/4 CZB 4
07 275249 DUCT, REAR (right) 1
08 271756 DOME LIGHT*** 1
09 272099 DUCT, REAR (left) 1
10 651783 SCREW/TPH TF CR#8-32x3/4 CZY AR
272579 #8 TINNERMAN AR
12 COVER (hoses and harness)
270842 (when equipped with A/C-Heater) 2
275241 (when not equipped with A/C-Heater) 1
13 L70487 SCREW, #10-16 x 3/4” 4
14 137503 LOUVER, ROLL NOZZLE 2
15 275291 INSULATION, DUCT (left-shown) 1
270246 INSULATION, DUCT (right-not shown) 1
16 271899 HOSE, FLEX. DUCTING 17.5 IN. 2
087850 CLAMP, HOSE #40 (not shown) 4
17 271670 BRACKET, FRONT COVER (upper) 2
18 271450 HOSE ADAPTER, 90º 2.50 IN. 2
Item
No. Part No. Description Qty.
19 271671 BRACKET, FRONT COVER (lower) 2
20 650448 CS 1/4 x 3/4 C5ZY 4
21 271898 HOSE, FLEX. DUCTING 31.5 IN. 2
087850 CLAMP, HOSE #40 (not shown) 4
22 274731 COVER, HVAC (left) 1
(Swing-Out Door - Option)
23 271394 LOUVER 2.50 IN. 4
24 271395 LOUVER, HOSE ADAPTER 2
25 274842 COVER, HVAC (right) 1
(Swing-Out Door - Option)
26 274734 BRACKET, SIDE COVER MOUNT 2
650448 CS 1/4 x 3/4 C5ZY (not shown) 4
071401 HLN 1/4 CZY (not shown) 4
651783 SCREW #8-32 x 3/4 (not shown) 4
27 275882 BULB, 12V - 10 W 2
28 50300088 BRACE, DOME LIGHT 1
29 651646 P TORX HTF #10-32x1/2 FBZ Type F 1
30 651312 RHMS SLT #10-24X1/2” CZY 4
* Used when the machine is not equipped with a heater or air
conditioning option.
** Used when the machine is equipped with a heater or air
conditioning option.
*** Does not include bulbs; order item #27.
Item
No. Part No. Description Qty.
NOTE: With the exception of items #3 and
#12—275241, all parts shown are only used
when the machine is equipped with the heater
or air conditioning option.
