Gehl RT250 - Page 47

Printed in U.S.A. 45 913364/BP0314
RT250 - CHASSIS
REAR ACCESS DOORS
06 50300863 HINGE 2
07 650758 CB 1/4" x 3/4" C5ZY 4
08 274655 PIN, 1/4" 4
09 210-32184 HN FL CLOC 1/4" CZY 4
10 50300881 DOOR, RIGHT 1
11 273576 LOCK CAM 2
12 131913 BUMPER 2
13 653034 HJN 5/16 C2ZY 2
14 064260 HLN INST 5/16 CZY 2
15 184670 PLUG, SQ MP12 1
16 271869 CAM LOCK 1
17 071401 HLN INST 1/4” CZY 4
18 50300223 SCREW, SHOULDERED 5/16' x 1/2" 2
19 271503 WELDMENT, TOOL BOX DOOR 1
20 50300862 DOOR, LEFT 1
-- ITEMS NOT SHOWN --
- - 192182 PLUG, RUBBER 1
(Located inside left tool box under the
battery on the front wall of the tool box.)
* For replacement key, order P/N 50280186.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
