Printed in U.S.A. 51 913364/BP0314
RT250 - ELECTRICAL
CHASSIS WIRE HARNESS / COMPONENTS
01 50220456 ECU (Electronic Control Unit) *1
02 50303584 CONTROLLER, MAESTRO II 1
03 273746 CONTROLLER, MAESTRO I 1
04 50303821 MODULE, CONTROL INTERLOCK 1
06 137959 CB 1/4" x 1-1/2" CBC ** AR
07 654004 FW 5/16" AWZY ** AR
08 071401 HLN INST 1/4" CZY ** AR
09 50300530 TIE/CABLE 0.50x9.10 AR
10 095619 CLAMP, HOSE 1.25 x 0.41 AR
11 50301225 BRACKET, HARNESS 2
12 651094 CB 1/4" x 1-1/4" C5ZY AR
13 653010 HN 3/8" C2ZY AR
14 652140 CB 1/4" x 2" C5ZY 3
15 122805 SPACER/BUSHING 3
16 50657006 CB #10-24 x 1 C2ZY AR
17 650584 FW #10 AZY AR
18 084175 HLN INST #10-24 CZY AR
19 193856 SOLENOID 1
(R12 - Glow Plugs)
20 195740 COVER, ELECTRICAL 1
21 275535 TRIM/EDGE 0.25-0.50 x 12.75 IN. 1
22 50301357 FUSE, 100 amp / AMG 1
(MEGA 1 - Glow Plugs)
191192 FUSE HOLDER (not shown) 1
23 064260 HLN INST 5/16 CZY 2
24 651086 CB 1/4" x 1" C5ZY AR
25 650545 CS 5/16" x 1-1/4" C5ZY 1
26 210-31017 HN LF CLOC 5/16 CZY 1
27 650588 CS 1/4" x 1-1/2" C5ZY 1
28 071700 LN 1/4" CBZY 1
29 183814 HORN, WARNING 1
33 656047 HN M6-1.00 C8 ZY DIN934 1
34 243319 CLAMP & COVER, BATT. POS. 1
35 273773 SWITCH, TRACK TENSION 1
36 651424 CS M6-1 x 20 C8.8 2
37 650448 CS 1/4" x 3/4" C5ZY AR
38 650573 CB 5/16" x 1" CBZY 2
39 055648 TIE/CABLE 0.19 x 7.50 IN. BLACK AR
40 242146 RELAY, ISO SPST/SEALED 1
(R1 - Main Power)
41 650835 CS 1/4" x 1" C5ZY AR
42 50302492 BRACKET, FUSE BOX 1
43 071701 LN 5/16" CBZY AR
46 650486 CS 5/16" x 3/4" C5ZY 1
47 132940 CLAMP, HOSE 0.81 x 0.47 IN. 1
48 242381 FUSE, MAXI 80 AMP 1
(MAXI 1 - Main Machine Power)
49 50300979 WIRE HARNESS, CHASSIS 1
(Includes fuse box and the fuses and
relays contained in the fuse box.)
50 50288219 FUSE BOX COVER (only) 1
(included with item 49)
*
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
NOTE: The ECU (Item 1) is a special order item
that requires programming. Please provide the
engine model and serial number when placing the
order for the ECU. Be aware: the programming
requirements may result in a delay in obtaining
this part.
** NOTE: These items are subject to change; vibration
isolating hardware may be substituted in later
production machines.
