Printed in U.S.A. 59 913364/BP0314
RT250 - ENGINE
EXTERNAL COMPONENTS
01 50302435 ENGINE, DEUTZ TD3.6L4/T4 1
(includes items 2, 3, and 4)
02 50220515 ALTERNATOR 1
03 50220511 BELT/ALTERNATOR-FAN 1
04 50220520 STARTER 1
05 50302348 FAN, ENGINE (20/31.5DEG/Push) 1
06 50300466 CS M8-1.25x65 C8.8 ZY SP 4
07 50302216 PULLEY, CRANKSHAFT (A/C) * 1
08 50301007 SPACER, FAN 1
09 50301875 DIPSTICK ASSEMBLY 1
(includes dipstick and tube)
10 650486 CS 5/16" x 3/4" C5ZY 1
11 136226 CLAMP, HOSE 0.75 " X 0.41" 1
12 131842 HN FL SLOC 5/16" C 1
13 50301877 BRACKET, DIPSTICK 1
14 656093 CS M8-1.25x16 C8.8 ZY 2
15 50302785 HEATER, OIL PAN 250 WATT (opt.) 1
(Kit includes heater, silicone sealant
sandpaper, scraper, wire ties, and
installation instructions.)
16 50303090 BRACKET, DIPSTICK RETAINER 1
17 50303105 WASHER, SEALING 1
18 145833 FW 1/2 HT ZY 2
19 50301039 CS FLH M12-1.75x25 10.9ZY SP 2
* When equipped with the air conditioning option.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
NOTE: Refer to the engine parts manual—
Form #50960058—for additional engine parts.
