Printed in U.S.A. 65 913364/BP0314
RT250 - ENGINE
FUEL TANK
01 271468 CAP, FUEL 1
50280186 KEY, 8001 (14603) (not shown) 1
02 272426 STRAINER, FUEL 1
03 50302508 TANK, FUEL 1
04 651202 MS HHM USL #10-24 x 3/4” C2ZY 5
05 271459 SENDER, FUEL LEVEL 1
50300425 GASKET (not shown - included with
the sender; also use Permatex® Blue
sealant on the gasket)
06 50301585 BUSHING, RUBBER 1/2" 2
07 50302360 FITTING, FUEL TANK 1/2" 2
08 087852 CLAMP, HOSE #06 6
09 50302359 HOSE, FUEL 1/2" x 5" 1
10 50302436 FUEL PUMP, ELECTRIC 12 VDC 1
(includes item #11) (Fuel Transfer)
11 NSS FITTING (included with item #10) 1
12 651203 LN #10-24 CBZY 4
13 651202 MS HHM USL #10-24 x 3/4” C2ZY 4
14 50302362 HOSE, FUEL 3/8" x 24" 1
15 073024 BUSHING, RUBBER 3/8" 2
16 50302553 FITTING, FUEL TANK 3/8" 2
17 50301595 HOSE, FUEL 3/8" x 70" (return) 1
18 50301589 HOSE, FUEL 1/2" x 85" (supply) 1
19 50302205 PAD, RUBBER 1
(Prevents chaffing between fuel tank
and the fuel tank bracket on the frame.)
20 50303242 FOAM, FUEL TANK 1
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
IMPORTANT: The fuel transfer pump (50302436) looks
similar to the fuel supply pump (50288223)—used near
the fuel filters to supply fuel to the engine; however, the
internal components of the pumps are different. Be sure
to order the correct part for the correct application. The
engine fuel supply pump is shown on the previous page;
item 17.
To Next Page
