Printed in U.S.A. 67 913364/BP0314
RT250 - ENGINE
AIR INTAKE
01
a
192587 PRECLEANER (option) 1
02
a
272318 ADAPTER, 2.75 - 4.0 IN. (option) 1
03
a
088937 CLAMP, HOSE SAE #64 (option) 1
04 183998 CLAMP, AIR CLEANER 1
05 650745 CB 5/16 x 1-1/4 C5ZY 2
06 210-31017 LN FL CTR 5/16 CFZY 4
07 187725 EVACUATOR VALVE 1
08 187726 AIR CLEANER, END CAP 1
(includes item 7)
09 NSS AIR CLEANER HOUSING 1
10 184146 AIR FILTER (primary) 1
11 184195 AIR FILTER (secondary) 1
12 186014 AIR CLEANER ASSEMBLY 1
(includes items 7-11)
13 184605 CLAMP, T-BOLT 3.50 IN. 3
14 184278 COUPLING, INTAKE HOSE 1
15
b
50303269 HOSE, AIR INTAKE 1
16 272300 FITTING, AIR RESTRICTOR 1
17 272299 INDICATOR, SERVICE 1
18
c
50303160 PLATE, AIR CLEANER MOUNT 1
19
c
650487 CS 5/16" x 1" CZY 2
20
d
176653 CS FLH M10-1.50X25 8.8ZY SP 1
21
d
50303167 BRACKET, INTAKE HOSE SUPPORT 1
22
d
650448 CS 1/4" x 3/4" C5ZY 1
23
d
210-19469 HN FL SLOC 1/4" CZY 1
24
d
50303166 CLAMP, HOSE 3.50" x 0.28" 1
a Precleaner option includes items 1-3.
b Early units used a different hose that required items
20-24 to secure the hose in place. The new hose does
not require the use of items 20-24; they should be
removed from the machine and discarded when
installing the new hose (PN 50303269).
c Used on early-style machines; not used with late-style
machines.
d Used on early machines that required support for the
early-style air intake hose.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
