Gehl RT250 User Manual

Printed in U.S.A. 71 913364/BP0314
RT250 - ENGINE
AIR CONDITIONING COMPRESSOR — (OPTION)
01 50301193 V-BELT A x 41 1
02 50302216 PULLEY, CRANKSHAFT (A/C) 1
03 50301163 SHCS M16-2 x 50 C12.9 CG SP 2
04 650579 CS 3/8 x 1-3/4 C5ZY 1
05 654049 FW 3/8 ANZY 2
06 139952 PULLEY w/BEARING (includes #7) 1
07 NSS BEARING (included with item #6) 1
08 241385 SPACER, PULLEY 1
09 071703 LN CTR 3/8 CBZY 4
10 241010 SE-G18 BELT TENSIONER 1
13 651395 CS M10-1.5x30 C10.9 ZY DIN931 * 1
14 656103 LW M10 ZY DIN127 * 1
15 50301045 MOUNT, A/C COMPRESSOR 1
16 650965 CS 3/8 x 1-1/4 C8 3
17 241310 A/C COMPRESSOR ASSEMBLY 1
18 50301159 CS M10-1.4x45 C8.8 ZY SP 6
19 138781 HWHMS M10 x 30 MM 1
20 241303 MANIFOLD, COMPRESSOR A/C 1
21 140780 O-RING SET 1
22 NSS A/C COMPRESSOR HOUSING 1
23 139288 CLUTCH, A/C COMPRESSOR 1
* Included with item #10.
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.

Gehl RT250 Specifications

General

Rated Operating Capacity	2, 500 lbs
Engine Power	74 hp
Tipping Load	5, 000 lbs
Auxiliary Hydraulics - High Flow	35 gpm
Engine Net Power	74 hp
Engine Gross Power	74 hp
Overall Length with Bucket	146.2 inches
Width	72 inches
Horsepower	74 hp
Length with Bucket	146.2 inches
