Printed in U.S.A. 85 913364/BP0314
RT250 - LOADER ARM
BOLT-ON COMPONENTS
01 570002 FITTING, GREASE 1/8 PTF 2
02 271363 BUSHING 4
03 650653 CS 1/2 x 4-1/2 C5ZY 2
04 50300837 PIN, HEAT TREATED 2
05 068034 HLN INST 1/2 CZY 2
06 064354 CS FL LOCK 5/16 x 1 C5ZY 8
07 273624 SHIELD 1
08 650581 CS 3/8 x 3 C8ZY 2
09 50352739 BLOCK, COUPLER/PRESS. RELF. 1
10 274598 SPACER, COUPLER BLOCK 1
11 272758 WELDMENT, HANDLE - (LEFT) 1
12 50302491 BUSHING, SPRING CROSS * 4
13 272759 WELDMENT, HANDLE - (RIGHT) 1
14 650934 THWH TC USL 3/8 x 1 CZY 1
15 272398 COVER, LOADER ARM 1
16 276038 STEP 1
17 650758 CB 1/4 x 3/4 C5ZY 4
071401 HLN INST 1/4 CZY (not shown) 4
18 275977 PLATE (bracket)** 1
19 137059 COUPLER, FEMALE MJ12 ** 1
20 131958 COUPLER, MALE MJ08 ** 1
21 137058 COUPLER, MALE MJ12 ** 1
22 076589 CS FL LOCK 3/8 x 1 *** 2
23 064354 CS FL LOCK 5/16 x 1 C5ZY ** 4
24 276002 SHIELD *** 1
25 50302324 CHANNEL (safety bar) *** 1
26 50302169 KNOB 1
071703 LN CTR 3/8 CBZY (not shown) 1
(used as a jam nut for knob)
27 650663 CS 1/4" x 5/8" C5ZY 2
28 50301796 ISOLATOR 0.75" x 1 " RUBBER 3
29 50302541 TETHER 1
30 071700 LN 1/4" CZY 1
(used to attach tether to under loader arm)
31 650748 CB 1/4" x 5.8" C5ZY 1
32 50300624 WELDMENT, LOADER ARM 1
33 243009 GROMMET 0.69 x 0.25 x 1.0 PLUG 2
274998 PLUG, PLASTIC 1.0"
(use grommets or plugs based on machine options)
34 137637 DECAL, KEEP OUT/LIFT ARM 1
* Refer to “Attachment Bracket” (located on the next page)
for attachment bracket pins and related parts information.
** Used when machine is equipped with high-flow
hydraulics option.
*** IMPORTANT: When ordering this part, be sure to
also order and affix item #34 warning decal .
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
To Next Page
