Gehl RT250 User Manual

Printed in U.S.A. 91 913364/BP0314
RT250 - LOADER ARM
14-PIN CONNECTOR (OPTION)
01 50301592 JOYSTICK, 14-PIN 1
02 651086 CB 1/4" x 1" C5ZY 4
03 50302118 STAND-OFF, 1/4"-20 x 2" 2
04 650863 FW 1/4" ANZY 2
05 650663 CS 1/4" x 5/8" C5ZY 2
06 50301778 WIRE HARNESS, 14-PIN AUX. 1
(includes items 21-34, and fuse box #35)
07 210-19469 HN FL SLOC 1/4" CZY 2
08 650692 CS 5/16" x 1-3/4" C5ZY 2
09 L69833 PLATE, TOP SIZE 2 TWIN 2
10 190950 CLAMP, TUBE 1.0 IN. TWIN 2
11 087852 CLAMP, HOSE #06 2
12 50301967 TUBE, 14-PIN ROUTING 1
13 50301781 WIRE HARNESS, 14-PIN CONN. 1
14 242633 GROMMET 3/8" ID 1" OD 1
15 210-31017 HN LF CLOC 5/16 CZY 2
16 50301976 BRACKET, 14-PIN CONN. 1
17 50301964 CLAMP, MUFFLER 1-1/8" 1
18 210-32183 NUT, #8-32 1
19 310-32288 SCREW, #8-32 x 3/4" 1
20 194507 DUST CAP (with chain-not shown) 1
21 184629 FUSE, MINI 20 AMP 1
22 184631 FUSE, MINI 10 AMP 1
23 184630 FUSE, MINI 15 AMP 1
24 187347 DIODE, ISO 280 MINI/1A 400VDC 1
25 187347 DIODE, ISO 280 MINI/1A 400VDC 1
26 184629 FUSE, MINI 20 AMP 1
27 184631 FUSE, MINI 10 AMP 1
28 184630 FUSE, MINI 15 AMP 1
29 187347 DIODE, ISO 280 MINI/1A 400VDC 1
30 187347 DIODE, ISO 280 MINI/1A 400VDC 1
31 272723 RELAY, MICRO ISO 290 1
32 272723 RELAY, MICRO ISO 290 1
33 272723 RELAY, MICRO ISO 290 1
34 272723 RELAY, MICRO ISO 290 1
35 NSS FUSE BOX PANEL (included with #6) 1
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
Item
No. Description / Rating Function
21 FUSE, MINI 20A MAIN FUSE TO ARMING RELAY
22 FUSE, MINI 10A POWER TO JOYSTICK
23 FUSE, MINI 15A POWERS RELAYS 12, 13, AND 14
(POWER TO 14-PIN CONNECTOR PINS A, C, AND D)
24 DIODE, 1A, 400VDC PARALLEL TO JOYSTICK SWITCH 2 (UP)
25 DIODE, 1A, 400VDC PARALLEL TO JOYSTICK SWITCH 3 (UP)
26 FUSE, MINI 20A SPARE FUSE
27 FUSE, MINI 10A SPARE FUSE
28 FUSE, MINI 15A SPARE FUSE
29 DIODE, 1A, 400VDC PARALLEL TO JOYSTICK SWITCH 2 (DOWN)
30 DIODE, 1A, 400VDC PARALLEL TO JOYSTICK SWITCH 3 (DOWN)
31 RELAY, N.O. 35A / N.C. 20A ARMS SWITCHES AND RELAYS
32 RELAY, N.O. 35A / N.C. 20A POWER TO 14-PIN CONNECTOR PIN A
33 RELAY, N.O. 35A / N.C. 20A POWER TO 14-PIN CONNECTOR PIN C
34 RELAY, N.O. 35A / N.C. 20A POWER TO 14-PIN CONNECTOR PIN C
14-Pin Connector Fuse Panel Reference
