Gehl RT250 User Manual

Printed in U.S.A. 97 913364/BP0314
01 273628 HOSE, MP10 x 104.0 IN. 1
02 273628 HOSE, MP10 x 104.0 IN. 1
03 273860 HOSE, MP6 x 103.0 IN. 1
04 650733 CS 5/16 x 2-1/2 C5ZY 1
05 136226 CLAMP, HOSE 0.75 x 0.41 (vinyl) 1
06 650581 CS 3/8 x 3 C8ZY 1
07 50352739 BLOCK, COUPLER W/PRESS. RELF. 1
(includes items 12-16)
08 274598 SPACER, AUXILIARY COUPLER 1
09 054994 ST MJ06-MORB06 1
10 079098 PLATE, TOP 1
11 190950 CLAMP, TUBE 1.00 TWIN 1
12 50352909 COUPLER, MALE (flat face) 1
13 50352912 COUPLER, RETURN (flat face) 1
14 50352910 COUPLER, FEMALE (flat face) 1
15 NSS BLOCK, MANIFOLD 1
16 50352914 FITTING KIT 3/4" SAE 2
18 064354 CS FL LOCK 5/16" x 1" C5ZY 4
19 273624 SHIELD 1
20 137542 90 BLKHD MJ10-MJ10 2
21 098534 90 BLKHD MJ06-MJ06 1
HOSE CONNECTION:
#01 connects to bulkhead tee - hose to self-level valve (A3)
#02 connects to bulkhead tee - hose to self-level valve (B3)
#03 connects to bulkhead tee - hose to hydraulic tank return
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
RT250 - LOADER ARM
AUXILIARY HYDRAULICS CIRCUIT - (STANDARD)

Gehl RT250 Specifications

General

Rated Operating Capacity	2, 500 lbs
Engine Power	74 hp
Tipping Load	5, 000 lbs
Auxiliary Hydraulics - High Flow	35 gpm
Engine Net Power	74 hp
Engine Gross Power	74 hp
Overall Length with Bucket	146.2 inches
Width	72 inches
Horsepower	74 hp
Length with Bucket	146.2 inches
