Menu levels Submenu Display Function Value range Default setting
Error Level Maximum system devi-
ation
(error output)
AUTO, 0.0 ... 100,0 % AUTO
Range Functn Range monitoring of set
value input
< 4 mA
> 20 mA
< 4 mA or > 20 mA
< 4 mA or > 20
mA
Position Output Submenu for setting the actual value output
Analog Out Defines the function of
the actual value output
0–10 V, 0–20 mA*,
4–20 mA*
0–10 V
Out min Valve position on actual
value output signal 0 V
(0/4mA*)
0.0 ... 100.0 % 0,0 %
Out max Valve position on actual
value output signal 10 V
(20 mA*)
0.0 ... 100.0 % 100 %
CpyParaSet Copies parameters to
various working memor-
ies (P1/P2/P3/P4)
4 SetCalibration X-DIR Direction of X display and
actual value output
RISE, FALL RISE
Setp Dir Direction of set value NORMAL, INVERSE NORMAL
Setp Ramp Ramp function - set value AUTO,
0 to 400 s
0 s
Split Start Split range (set value
range) start
0.0 ... 90.0 % 0,0 %
Split End Split range (set value
range) end
10 ... 100 % 100 %
Setp Fn Defines the function of
the control characteristic
Linear/ free / 1:25 /
1:50
Linear
Setp Functn Submenu for setting the set value calibration points (only possible with "Setp Fn:
free")
W 0 % 10 control characteristic
points can be pro-
grammed as desired
0 ... 100.0 % 2.0 %
W 10 % 0 ... 100.0 % 3.0 %
W 20 % 0 ... 100.0 % 4.4 %
W 30 % 0 ... 100.0 % 6.5 %
W 40 % 0 ... 100.0 % 9.6 %
W 50 % 0 ... 100.0 % 14.1 %
W 60 % 0 ... 100.0 % 20.9 %
W 70 % 0 ... 100.0 % 30.9 %
W 80 % 0 ... 100.0 % 45.7 %
W 90 % 0 ... 100.0 % 67.6 %
W 100 % 0 ... 100.0 % 100.0 %
*Only available on version with optional current output
17 System mode ADVANCED
