GEM 1435 ePos - Page 46

www.gemu-group.com46 / 71GEMÜ 1435 ePos
17 System mode ADVANCED
17.2.3.1.4 1435 specific
NOTICE
▶ Certain Active Levels are required (see “Activating or deactivating user access“, page47) in order to read and edit the
parameters.
Submenu for displaying the tool identification
Display Function Value range Default setting Active level
Read Edit
Release Displays current soft-
ware release
V2.X.X.X 0 o.r.*
1)
S/N Displays current serial
number
0 o.r.*
1)
TAG1 A TAG number can be
entered
0 3
TAG2 A TAG number can be
entered
0 3
1) o.r. = only readable
17.2.3.2 Explanation of parameters for 1 Service
17.2.3.2.1 Scanning the input and output signals
I / O Status
1.1
Service
1
SetFunction
3
SetCalibration
4
Communication
5
SetBasics
2
SETUP
Min-Pot-Max:
Displays the minimum and maximum travel sensor position in percent. To ensure correct function, this value must lie between
2% and 98%.
Iw / Uw:
Displays the value of the current set value signal compared to the current valve position in %.
W Pos X:
Displays the current travel sensor position (Caution, this value may be different to the Pos x value as the valve does not make
full use of the full 0-100% range of the travel sensor).
Valve:
Displays the current position of the internal pilot valves (valve open = )
