Operation
30 MGG100M Operating Manual 36833 C
Pipe Diameter and Fuel Flow Rate
Pipe diameter determines the rate at which a fuel flows to the unit. To attain a workable flow rate, you must choose
a suitable pipe size.
• The required NG fuel flow-rate for the unit is 1,320 ft
3
/hr (37.38 m
3
/hr). To determine pipe diameter for your
application, see Table 1, below.
• The required LPL fuel flow-rate for the unit is
8.5 gph (32.2 Lph). To determine pipe diameter for your application, see
Table 2, below.
Note: Almost all operation problems are related to the installation techniques used. DO NOT guess; be sure pipe
diameter is adequate for required flow rate.
Table 1 - NG Flow Rate (Ft
3
/Hr) At Pipe Length
Pipe Length
(Feet)
Iron Pipe Size (Diameter)
1/2″ 3/4″ 1″ 1−1/4″ 1−1/2″ 2″ 2−1/2″ 3″ 4″ 6″ 8″
15 73 165 332 722 1174 2386 3704 6253 13352 37229
30 50 115 232 515 818 1712 2646 4521 9331 26330 53728
45 41 95 191 418 673 1419 2213 3752 7600 22462 43867
60 37 83 166 366 587 1241 1924 3319 6542 18595 37999
75 74 149 332 524 1077 1684 2886 5772 16652 33959
90 67 137 298 433 962 1501 2597 5291 15200 31025
105 63 126 274 415 885 1376 2357 4906 14064 28715
120 115 260 404 827 1289 2213 4618 13160 26859
150 105 233 366 750 1174 2011 4185 11775 24050
180 96 216 337 693 1077 1876 3848 10736 21934
210 89 197 308 635 991 1712 3559 9937 20298
240 183 289 596 933 1616 3357 9235 18990
270 171 274 558 875 1520 3127 8658 17903
300 164 260 524 827 1433 2886 8177 16998
