Generac Power Systems Tower Light HYDRO POWER CUBE User Manual

HYDRO POWER CUBE 9mt 4x150W LED
16
TL113-01-10-00
23-09-2013
11.3 HYDRAULIKSTEUERUNG – HYDRAULIC GEAR BOX
11.3.1 ELEKTROMOTOR – ELECTRICAL MOTOR
Versorgung
230 V 50-60 Hz ± 10%
Feeding
Leistung
0,55 kW
Power
Pole
4
Poles
Lastfaktor
S1
Duty factor
11.3.2 HYDRAULIKPUMPE – GEAR PUMP
Hubraum
1,3 cm
3
Displacement
Höchstdruck
210 bar
Maximum pressure
Werkseitig eingestellter Druck
180 bar
Factory setting pressure
Notfallaktivierung
Manuell - Manual
Emergency action system
11.3.3 MAGNETVENTIL – UNLOADING SOLENOID VALVE
Wärmeisolierung Spule
Class F – VDE0585
Coil thermal insulation
Elektrischer Anschluss
DIN 43650-A / ISO 4400
Electric connection
Schutzgrad
IP 65
Protection degree
Impulse
ED 100%
Coil duty cicle
Spulenspannung
230 V 50-60 Hz ± 10%
Coil voltage
11.3.4 HYDRAULIKÖL – HYDRAULIC FLUID
Fassungsvermögen Tank
5 l
Reservoir capacity
Öltype
ISO/DIN 6743/4
Mineralöl - mineral oil
Fluid type
Öl-Viskosität
15-100 mm
2
sec –
ISO 3448
Fluid viscosity
Öltemperatur
-15°C ÷ +80°C
Fluid temperature
Max. Verschmutzungsgrad des Öls
Klasse 10 laut NAS 1638
mit Filter B 25 > 75 –
Class 10 in accordance
with NAS 1638 with filter
B 25 > 75
Fluid maximum contamination
level
