Genie GCL-GCX User Manual

5.3
External Wire Diagram
See Appendix B for detailed description of terminals.
1-BTN
STATION
KEY
SWITCH
STATION
CARD
READER
O/C
PULL
SWITCH
N/O
N/O
N/O
N/O
REMOVE
JUMPER
WHEN
INSTALLING
EXTERNAL
INTERLOCK
MULT PLE
3 BUTTON
STAT ON
NSTALLAT ONS
REQU RE THE
STOP BUTTON
TO BE W RED
N SER ES
See Fig 5 pg 5 4
*
EXT
INTLK
EXT
INTLK
N-O
REVERSE
N-O
REVERSE
ODC
STB
ODC
STB
1-BTNGNDSTOPCLOSEOPEN
EXT RAD O CONNECTOR
SENSING EDGE SWITCH
(DO NOT CONNECT
2-WIRE MONITORED
SENSING EDGE SWITCH
TO THESE INPUTS)
THRU-BEAM PHOTOCELLS
2-WIRE MONITORED SENSING EDGE SWITCH
+
-
+
-
PWR
20 40 VDC @ 315mA
MAX CURRENT
RELAY
GND
NOM
+ 24VDC
RADIO
SERIES II SAFE-T-BEAM
®
(STB)
(
*
CONNECT STB WIRES
TO EITHER TERMINAL)
*
OPEN
CLOSE
STOP
REMOVE
JUMPER
IF STOP
BUTTON
IS USED
3-BUTTON
STATION
*
BLUE
ORANGE YELLOW
Located inside
Electrical Box
MONITORED EDGE
INTERFACE MODULE
(OPAKMEIGX.S)
www.geniecompany.com 08-12
Counter Door Operator
GCL-GCX
