Genie GCL-GCX User Manual

GCL-GCX
Section 7: Special Operator Features (No user input)
OPEN
CLOSE
STOP
CYCLES 1
Figure A
OPEN
CLOSE
STOP
GDO V# #########
OPEN
CLOSE
STOP
CAL
RUN
SCROLL
SET
CLEAR
DISPLAY V# #######
Figure B
Operator Cycle Count
GDO and Display Firmware
CAL
RUN
R N
SCROLL
P
CAL
RUN
CAL
RUN
C
N
SCROLL
CAL
RUN
1) Press CAL/RUN to enter calibration mode.
2) Press SCROLL until display reads “GDO V# > ######.” Figure B.
This display will cycle between the version number of the current GDO
firmware and the current Display Firmware.
3) Press CAL/RUN to return to run mode.
1) Press CAL/RUN to enter calibration mode.
2) Press SCROLL until display reads “CYCLES>1,2,3 etc.
where the number is the number of open/close cycles the operator
has performed. Figure A.
3) Press CAL/RUN to return to run mode.
7.1
www.geniecompany.com 08-12
Counter Door Operator
